Application scope
It is applicable to the suction of heavily-polluted working environment, such as: aerosol of Stomatology Department, the gas or light dust in Dermatology Department, Atomizing Chamber, Gynecology Department and laboratory and for soldering tin full of the smoke and dust.
Applicable industry
Laboratory pharmaceutical industry, electronics factory, chemical industry, food industry, Dental Department, laser electrotome, laboratory, Atomizing Chamber, Gynecology Department, Dermatology Department, Cosmetology Department, machine shop, cultural relic repair, etc.
JYLB-800-SFD/SD
| Inner diameter of air outlet: 90 Outer diameter 95 | Air volume damper |
|
|
|
Technical Parameter
|
Model |
Material arm |
Spring |
Size of air outlet |
Pipeline caliber |
Seal ring |
Activity radius |
Installing support and method |
Size of node arm A, B, C, D, E |
Recommended air volume |
Color |
Filter element |
Valve |
Remarks |
|
JYLB-780-SFD |
Aluminum oxidation |
304 Stainless steel |
Φ90 |
Φ78 |
POE |
1.2-1.8 m |
Ceiling type |
1000, 300, 650, 550, 200 |
80-180mᶾ/h |
White |
Configurable |
√ |
|
|
JYLB-780-SD |
Aluminum oxidation |
304 Stainless steel |
Φ90 |
Φ78 |
POE |
1.2-1.8 m |
Ceiling type |
1000, 300, 650, 550, 200 |
80-180mᶾ/h |
White |
Configurable |
× |
Description of product configuration
Brand: Jingyu
Product name: Universal Fume Extraction Arm
Diameter of tubular arm: Φ78
Air valve: The hemispherical air valve can achieve the stepless adjustment of air volume
Size of gas-collecting hood: Circle: Φ160, circle: Φ220, circle: Φ350
Square: 420×320 or 620×420 (optional)
Color: Transparent
Installing support: 400, 700, 1000, 1200 (optional)
Material: Stainless steel plastic spraying
Parameters of gas-collecting hood
|
Picture |
|
|
|
|
|
Size |
420×320 |
Φ350 |
Φ220 |
Φ160 |
|
Color |
Transparent |
Transparent |
Transparent |
Transparent |
|
Material |
PC |
PC |
PC |
PC |
|
Shape |
Square |
Circle |
Circle |
Circle |
|
Usage |
Used in condition with a large suction area in laboratory as well as a face velocity of about 0.1-0.3m/s |
Used in condition with a large suction area in laboratory as well as a face velocity of about 0.1-0.3m/s |
Used in condition with a small suction area in laboratory as well as a face velocity of about 0.5-1m/s |
Used in the condition with a small suction area in laboratory and a face velocity of over 1.5m/s |
